Installation Guides

Hold the brackets in place and put two screws in each bracket. We’ve supplied you with 2x high-quality (colour-matched) screws for each bracket. You can use a manual or electric screwdriver, and there’s no need to pre-drill a pilot hole.

Now your brackets are in place, all you need to do is slot in your blinds. You’ll notice that both ends of the tube are slightly different. One is has a “female” connector, the other is springy “male” connector; you need to insert the blinds’  “female” side first (into the brackets’ male connector) and the repeat for the blind’s springy “male” connector into the bracket’s “female” connector.

The final step is installing the supplied clip to keep your chain tidy and safe for children. We recommend installing this with a bit of slack to allow for a smooth operation.

That’s it; it’s as easy as that.

Inside Fit: Position LH bracket in top LH corner and secure in place using 2x screws provided. Repeat steps for RH bracket. Ensure brackets are level.

Outside Fit: Attach LH bracket using measurements you initially took.
If installing near the frame edge, pre-drill to prevent splitting. For wall mounting, use spacers/packers and longer screws to allow proper clearance.
Follow same steps for RH bracket.

Install centre bracket if provided.

Detach control cord bundle from top of headrail. Open latches on end brackets.

Place headrail into brackets, ensuring control cords are on correct side. Insert headrail into brackets, ensure control cords are on correct side. Push latches on both sides closed. Make sure both “click” into place.

Remove protective tape from velcro tabs attached to headrail. Align the pelmet with top of blind and press it firmly onto the velcro tabs. Carefully untie the fabric straps while holding the blind in place.

Note: Aluminium Venetians do not have pelmets.

We’ve supplied you with 2x “spring Clips” that fit our 25mm Venetian Blinds’ top bar perfectly. Simply screw in the clip to the top of your window (as pictured) ensure that the clip will not be obstructed by any of the control mechanisms.

Note that the clip has a bigger curve at one end. This is the side to screw in to your window frame.

Now you just firmly press the top bar into the clips. Make sure that you sit the back bottom lip of the top bar into the clip’s grip. When this is resting in place, continue to confidently bend the spring clip with your top bar, applying pressure until the blind “clicks” into place.
